Specifications of rear wheel disc brakes

Teves brand rear wheel brakes with solid discs, fixed caliper, two-piston, with integrated parking brake pads.

Characteristics of brake discs

Disc outer diameter, mm: 260.

Nominal disc thickness, mm: 10.

Minimum thickness after grinding of each side, not less than, mm: 8.

Roughness of the working surface of the disc after grinding, microns: 10.

Minimum thickness of the disc during wear, not less than, mm: 7.

Permissible difference in the thickness of the working surface of the disk, not more than, mm: 0.01.

Axial runout of the working surface of the disc, no more than, mm:

• when measured on a removed disk: 0.03;
• when measured on a car: 0.10.

Permissible depth of wear marks on each side of the disk, not more than, mm: 0.4.

Characteristics of the friction linings of the brake mechanisms of the rear wheels

Brake pads

Brand and type: Textar T414.

Overall friction lining thickness (along with the underlay), mm: 15.

Friction lining dimensions, mm: 61.8x40.5x11.

Minimum total friction lining thickness (along with the underlay) at wear, not less than, mm: 7.

Wheel cylinders

Piston diameter, mm: 35.
